Portable xeb ntxuav Laser
Siab Precision.
Ceev ceev.
Kev ua haujlwm yooj yim.
Kev tu yooj yim.
Hauj lwm lawm
Portable xeb ntxuav Laser
Product Description
Compact thiab ntau yam, portable xeb tu laser yog tsim los rau cov nqi kho mob ntawm cov cheeb tsam me me uas yuav tsum tau maj mam siab precision tu, de-coating thiab lwm yam kev kho deg.
Lub hauv paus system muaj xws li laser qhov chaw, nrog rau kev tswj thiab txias, ib tug fiber optic rau beam xa thiab ib tug ua lub taub hau. Ib qho yooj yim lub ntsiab fais fab mov yog siv rau kev khiav hauj lwm nrog ib tug heev tsawg zog thov.
Tsis tas yuav tsum muaj lwm yam xov xwm los kho qhov chaw. Cov tshuab laser no yooj yim rau kev khiav lag luam thiab tsis muaj kev saib xyuas zoo.
Khoom nta
1. Tsis muaj kev puas tsuaj rau lub hauv paus ntawm cov khoom siv vim tsis muaj qhov kov ntawm qhov kev ua haujlwm tu.
2. Cov txheej txheem tu huv huv rau thaj chaw tshwj xeeb hauv thaj chaw xaiv.
3. Tsis xav tau chemistry lossis lwm yam khoom siv ntxiv.
4. Portable xeb ntxuav laser yooj yim ua haujlwm, tuaj yeem tuav tes lossis nws pib ntxuav los ntawm kev txhim kho lub caj npab robotic.
5. Lub sij hawm tu me me thiab tuaj yeem ua tiav cov txiaj ntsig zoo.
6. ruaj khov thiab cuam tshuam kev tsim qauv uas ua rau tsis muaj kev saib xyuas ntxiv.
7. Txhawb kev ua haujlwm offline.
Khoom Parameters
Qauv | RL-C1000 Nws | Qauv: RL-C1500 | RL-C2000 |
Laser qhov chaw | Fiber Laser | Fiber Laser | Fiber Laser |
Laser zog | 1000W | 1500W | 2000W |
Fiber cable Length | 10M | 10M | 10M |
Lub wavelength | 10 80nm | 10 80nm | 10 80nm |
Lub taub hau ntxuav | Ib axis | Ib axis | Ib axis |
Ceev ceev | Tsawg dua lossis sib npaug li 60 M² / Teev | Tsawg dua lossis sib npaug li 65 M² / Teev | Tsawg dua lossis sib npaug li 70 M² / Teev |
Txias | Dej txias | Dej txias | Dej txias |
Dimension | 98 * 54 * 69cm | 98 * 54 * 69cm | 98 * 54 * 69cm |
Packing loj | 108 * 58 * 97cm | 108 * 58 * 97cm | 108 * 58 * 97cm |
Net nyhav | 120 KGS | 120 KGS | 120 KGS |
Qhov hnyav tag nrho | 140 KGS | 140 KGS | 140 KGS |
xaiv tau | Phau ntawv | Phau ntawv | Phau ntawv |
Kub | 10-40 degree | 10-40 degree | 10-40 degree |
Hwj chim | < 7KW | < 7.5KW | < 8KW |
Qhov hluav taws xob | Ib theem 220V, 50/60HZ | Ib theem 220V, 50/60HZ | Ib theem 220V, 50/60HZ |
Product Shipping
Riselaser Service Features
1. Cov khoom zoo nrog cov nqi sib tw.
2. 7 * 24 Teev online Tom qab - kev pab cuam muag khoom.
3. Kev xa khoom raws sijhawm thiab kev pabcuam zoo tom qab muag.
4. Lub neej kev txhawb nqa rau koj.
5. Txhua lub tshuab ntxhua khaub ncaws ntxhua khaub ncaws yuav raug kuaj ua ntej xa khoom.
Cim npe nrov: portable xeb tu laser, Suav teb, manufacturers, customized, lag luam wholesale, nqe, kub muag
